A Successful Machine Builder Conveyor Application From GAM
A machine builder improved speed control and positioning of chain conveyor system using a modified GAM Dyna-Lite gearbox. GAM provided a special input shaft to accept the hollow hex input from the customer’s conveyor drive.
Application Challenge:
A customer was looking to improve the positioning and speed control of their chain conveyor systems. They needed to replace the helical-worm gear-motors that were driving the conveyors with geared servo motors in order to achieve this goal. The conveyor drive inputs are hollow hex shaped and a six piece shaft adapter kit in order to connect the gearmotors is required. The challenge was Finding a gearbox that could properly interface with the hollow hex input.
The Solution with GAM
Engineers at GAM selected a Dyna-Lite right angle hypoid gearbox for the application. The output shaft was modified to a hex profile which allowed the gearbox to integrate directly into to the conveyor drive unit with just a single adapter plate. While the engineers could have provided a standard Dyna-Lite with a hex shaft assembly kit, this solution eliminated a total of five components, resulting in a more compact and easier to assemble system. Also provided, were tapped holes on the conveyor adapter plate so that a structure could be attached for supporting the motor and gearbox.
GAM offers a full source of gear reducers, servo couplings, linear mounting kits and other motion products used in automation technology. We are proud to be a distributor of GAM in Illinois and Wisconsin. Please contact us if you would like to learn more about this application or get a quote on GAM products.
A Successful Machine Builder Conveyor Application From GAM
A machine builder improved speed control and positioning of chain conveyor system using a modified GAM Dyna-Lite gearbox. GAM provided a special input shaft to accept the hollow hex input from the customer’s conveyor drive.
Application Challenge:
The Solution with GAM
Engineers at GAM selected a Dyna-Lite right angle hypoid gearbox for the application. The output shaft was modified to a hex profile which allowed the gearbox to integrate directly into to the conveyor drive unit with just a single adapter plate. While the engineers could have provided a standard Dyna-Lite with a hex shaft assembly kit, this solution eliminated a total of five components, resulting in a more compact and easier to assemble system. Also provided, were tapped holes on the conveyor adapter plate so that a structure could be attached for supporting the motor and gearbox.
GAM offers a full source of gear reducers, servo couplings, linear mounting kits and other motion products used in automation technology. We are proud to be a distributor of GAM in Illinois and Wisconsin. Please contact us if you would like to learn more about this application or get a quote on GAM products.
